Features

• It is designed for hydraulic crimping on power cable and wire.
• The crimped conductor is tested in high conductivity and close contact so that its uneasy to break out and turn hot.
• Open cut design for convenient operation.
• Dies are quickly put on tube by double speed unit.Then compression force lift and automatically change to low speed.The operation finished with energy saving and time shorten.
• The head could be rotated 180 degree freely for narrow space working.
• Fitted with safety valve,when pressure reaches to limited max,Value,pressure release automatically to prevent over pressure.
• Fiberglass insulated handles to prevent accidental electric hitting.
• Packing case is made from robust integral plastic box.

Product Specification

• Crimping range: 16-300mm²
• Maximum pressure: 12T
• Maximum stroke: 22MM
• Mold configuration: 16 25 35 50 70 95 120 150 185 240 300mm²
• Crimp form: confining pressure
